Synology DiskStation DS423 NAS strežnik, RTD1619B

Opis

Synology DiskStation DS423 je zmogljiv NAS strežnik s 4-jedrnim procesorjem RTD1619B (1.7 GHz) in 2 GB DDR4 RAM. Vključuje 2 ventilatorja (8 cm) za hlajenje in reže za diske (ni priloženih).

Specifikacije

Type

NAS

Depth

168 mm

Width

184 mm

Buzzer

Yes

Height

230 mm

Weight

2.21 kg

USB port

Yes

System log

Yes

Noise level

22.9 dB

RAID levels

0, 1, 5, JBOD, 10, 6

Cooling type

Active

Device class

Home & Home Office

Ethernet LAN

Yes

Fan diameter

8 cm

RAID support

Yes

Reset button

Yes

On/off switch

Yes

iSCSI support

Yes

Fan diameter 2

8 cm

LED indicators

Yes

Number of fans

2 fan(s)

Product colour

Black

Backup features

iSCSI LUN, Cloud

Backup function

Yes

Cable lock slot

Yes

Cables included

AC, LAN (RJ-45)

Internal memory

2 GB

Number of users

1024 user(s)

Processor cores

4

Processor model

RTD1619B

AC input voltage

100 - 240 V

Built-in display

No

Processor family

Realtek

Browser supported

Google Chrome, Firefox, Microsoft Edge, Safari

AC input frequency

50 / 60 Hz

Operating altitude

0 - 5000 m

Storage drive size

2.5/3.5"

Built-in FTP server

Yes

Built-in speaker(s)

No

Hot-swap drive bays

Yes

Processor frequency

1.7 GHz

Security algorithms

HTTPS, SSL/TLS, SSH, SSH-1.5, SSH-2

Cable lock slot type

Kensington

Internal memory type

DDR4

Multilingual support

Yes

Maximum RAM supported

6 GB

Power cables quantity

1

Power supply location

External

Card reader integrated

No

External power adapter

Yes

Processor manufacturer

Realtek

Supported file systems

HFS+, FAT32, ext4, BTRFS, exFAT, ext3, NTFS

Ethernet LAN data rates

100, 10, 1000 Mbit/s

Storage drives installed

No

Access Control List (ACL)

Yes

Power consumption (sleep)

4.97 W

Storage temperature (T-T)

-20 - 60 °C

Ethernet LAN (RJ-45) ports

2

Operating system installed

DiskStation Manager

Number of M.2 (M & B) slots

2

Operating temperature (T-T)

0 - 40 °C

Power consumption (typical)

32.41 W

Supported network protocols

SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV

Sustainability certificates

Federal Communications Commission (FCC), UKCA, CE, CCC

Installed storage drive type

No

Number of power supply units

1

Storage drive sizes supported

2.5, 3.5

Supported storage drive types

HDD & SSD

Storage relative humidity (H-H)

5 - 95%

Power supply unit (PSU) capacity

90 W

Operating relative humidity (H-H)

5 - 95%

Copper ethernet cabling technology

10BASE-T, 100BASE-T, 1000BASE-T

Maximum supported storage capacity

108 TB

Number of storage drives supported

4

Supported storage drive interfaces

Serial ATA

Redundant power supply (RPS) support

No

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2
